$319.00 USD

This LoRaWAN Wireless IOT sensor is designed to measure the tank level or open water applications while fully submersed in liquid. It is robust and sealed to prevent corrosion and failure.


• Customizable measuring range up to 200 m
• Submersible pressure sensor not affected by foam, wind, or rain
• IP67 full sealed plastic waterproof design (Transceiver is not included)
• Measuring medium: water (customizable for oil and other non-corrosive media)
• LoRaWAN® Wireless transmission
• Up to 10 Years Battery Life
• NFC wireless for easy configuration



 IOT-S500SWL Datasheet

 IOT-S500 User Guide

Qty available: 1 SKU:IOT-S500SWL-L003US
LoRaWAN Wireless Submersible Water Level Sensor with Long Life Battery
LoRaWAN Wireless Submersible Water Level Sensor with Long Life Battery
LoRaWAN Wireless Submersible Water Level Sensor with Long Life Battery
LoRaWAN Wireless Submersible Water Level Sensor with Long Life Battery
LoRaWAN Wireless Submersible Water Level Sensor with Long Life Battery

Submersible Water Level Sensor

IOT-S500SWL is designed to measure the tank level or open water applications while fully submersed in liquid. It is robust and sealed to prevent corrosion and failure.
  • Customizable measuring range up to 200 m
  • Submersible pressure sensor not affected by foam, wind, or rain
  • IP68 full sealed plastic waterproof design (Transceiver is not included)
  • Measuring medium: water (customizable for oil and other non-corrosive media)

LoRaWAN Wireless Submersible Water Level Sensor with Long Life Battery

Smart Water Management

In recent years, significant strides have been taken to implement IoT-based monitoring solutions in various areas such as liquid level measurement. Take water level in wells as an instance, monitoring and measuring the level with IoT-based system will protect users from running into serious problems such as water outages.
LoRaWAN Wireless Submersible Water Level Sensor with Long Life Battery

Smart Gasoline Management

Faced with increasing challenges, enterprises are continuously trying to deploy IoT technology into gasoline level monitoring and measurements to detect real-time accurate gasoline volume despite wide temperature swings, rough handling and harsh environments
LoRaWAN Wireless Submersible Water Level Sensor with Long Life Battery

Cloud Web & APP

IOT-S500SWL Sensor works perfectly with Linovision Cloud (Web & App), which allows you to monitor your data in the office or on the go. With a drag-and-drop experience, Linovision Cloud provides rich features such as intuitive widgets, triggers, sharing and transfer ownership of devices, layers, etc.
LoRaWAN Wireless Submersible Water Level Sensor with Long Life Battery

LoRaWAN Wireless Transmission

  • Ultra-low power consumption and easy deployment
  • Built-in 19000 mAh high-capacity battery can be used for 10 years.

Simple and Easy to Use

Configure Your Device via NFC
LoRaWAN Wireless Submersible Water Level Sensor with Long Life Battery
Download Toolbox
LoRaWAN Wireless Submersible Water Level Sensor with Long Life Battery
Turn on NFC and attach the sensor to the NFC area
LoRaWAN Wireless Submersible Water Level Sensor with Long Life Battery
Configure your sensor
